Model: CNME030402A
Features:
1.Discrete, colorimetry speed 240T/H (single/double reagent).
2.Rear spectrophotometry of holographic concave flat field grating, cluster-optical path,enables micro volume detection of reaction solution.
3.60nm polished probe, liquid level detection and collision protection.
4.Automatic digital liquid level detection, ensures stable performance, and reduces contamination carried by probe surface.
5.Multiple function sample & reagent disk,sample position and reagent position,users defined proportion according to the requirement, supporting various tubes and standard sample cuvettes.
6.LIS/HIS interface, also supports remote maintenance.
7.User-defined combined batch input of patient information, applicable to all customers' laboratories.
Specifications:
| Equipment type | Full automatic, discrete, STAT priority |
| Analysis rate | Colorimetry speed 240T/H(single/double reagent) |
| Sample reagent position | The reagent and sample share one disk,totally 67 positions. |
| Reagent volume | R1:10μl-350μl,R2:10μl~200μl,1μl stepping |
| Reaction cuvette | 120 positions optical plastic cup,optical diameter is 6 mm |
| Wavelength | 340nm,380nm,405nm,450nm,480nm,505nm,546nm,570nm,600nm,660nm,700nm,750nm or 800nm |
| Volume | 998mm×752mm×517mm(L×W×H) |
| Weight | 120Kg |
| Power supply | Voltage AC 220V±22V,50/60Hz,power 650VA |
| Packing size | 0.9m³ |
| GW | 145kg |
