X Ray DR System Medical Radiography Mobile X Ray Machine
  • X Ray DR System Medical Radiography Mobile X Ray Machine
  • X Ray DR System Medical Radiography Mobile X Ray Machine
  • X Ray DR System Medical Radiography Mobile X Ray Machine
  • X Ray DR System Medical Radiography Mobile X Ray Machine
  • X Ray DR System Medical Radiography Mobile X Ray Machine
X Ray DR System Medical Radiography Mobile X Ray MachineX Ray DR System Medical Radiography Mobile X Ray MachineX Ray DR System Medical Radiography Mobile X Ray MachineX Ray DR System Medical Radiography Mobile X Ray MachineX Ray DR System Medical Radiography Mobile X Ray Machine

Get Quotes

Download Full Catalogue

X Ray DR System Medical Radiography Mobile X Ray Machine

Model:CNME020102


Description:

CNME020102 mobile DR system could achieve high-frequency & high-voltage generator,excellent mechanical performance and intelligent auxiliary system design,and fully meet the demand of hospital digital radiography.


Technical datas:

Generator
Power
32kw(max 40kw)
KVp range
40-150kv
mA range
10-400mA
mAs range
0.1~500mAs
X-ray tube
Anode heat content
150KHu
Flat panel detector
X-ray sensitive
14*17inch
Physical specification
Weight
518kg
Height
182.5cm
Width
67cm
Column rotation range
±270°
Tube tilting angle
±180°
Tube vertical rotation angle
-30°~+90°
Telescopic arm length range
710~1240mm
SID
570~1800mm
