Model:CNME010804A
Description:
They are suitable for surgical procedures of the head, neck, thorax, abdomen, perineum and extremities as well as for gynecological, obstetrical, urological and laryngological operations. Various positions can be quickly and safely adjusted.
Specifications:
Dimensions of Table Top | |
Overall length | 2100mm |
Width | 480mm |
Dimensions of Sections | |
Head Rest | 280*320mm |
Back Section | 500*480mm |
Kidney Bridge | 85*415mm |
Seat Section | 450*480mm |
Leg Section | 500*480mm |
Foot Rest | 200*533mm |
Table Top from Floor | |
Min Height | 750mm |
Adjust | ≥200mm |
Range of Movements | |
Max Reversed Trendelenburg | ≥30° |
Max Trendelenburg | ≥20° |
Max Lateral Tilt | ≥18° |
Adjustments of Sections | |
Head-Rest raised from the horizontal | ≥45° |
Head-Rest lowered from the horizontal | ≥90° |
Back-Section raised from the horizontal | ≥75° |
Back-Section lowered from the horizontal | ≥18° |
Kidney Bridge Elevation | 120mm |
Leg-Section lowered from the horizontal | ≥90° |
Foot-Rest can be kept horizontally or perpendicularly to the Leg Section. | |
