Model:CNME05R0102
Features:
●4 in 1,camera+LED light source+ monitor+HD recorder.
●High brightness, 80watts LED.
● Medical grade HD monitor, 17 inch.
●With suitcase, easy to carry.
● Suitable for diagnosis and surgery.
● Application:Laparoscopy,Gynecology,Urology,ENT,Orthopedics,etc.
Detailed parameter as following table:
Medical Monitor | |
Screen size | 17’’ |
Color | 10.7 billion |
Aspect Ration | 5:4 |
Endoscope Full HD Camera | ||||
Image device | 1/2.8 CMOS | SNR | ≥50dB | |
SY | PAL | Brightness | ODS Adjustable | |
Scanning system | 2:1 progressive | White balance | Auto/MANUA | |
Scanning mode | Progressive scanning | AG | Low/medium/high/off grade adjustable | |
Horizontal Resolution | 1000TVL | Minimum Ⅲumination | F1.2≤0.11Lx | |
OSD Control-Menu | Built in
| external | DNR | 3D VOX |
LED Light Source | |||
Input power | 80VA | Light output hole diameter | φ（10±0.10）mm |
Light source | LED | Working conditions | 5℃~+40℃ |
Brightness | ≥1,200,000Lux | Storage conditions | -40℃～+55℃ |
Color temperature | ≥6500k | Continuous working hours | >4h |
HD Recorder | |||
Specifications | Parameters | External U flash disk | Max 64G |
Recordering format | MP4 | External mobile HDD | Max 2T |
Recordering quality | MAX 18Mbs @1080P 30Fps | Recorder interface | Support USB disk &removable hard disk |
Package details:
Size:65*58*25cm,G.W.:13.1kg.
