Model:CNME010510
Function:
1.Anti-bolus.
2.Can change the flow rate and VTBI without stopping the infusion.
3.Intelligent pressure detection alarm.
4.History records more than 30000, can be transmitted to computer.
5.Heating function.
6.Standby function: 1 min - 24 hrs adjustable.
7.Adjustable buzzer volume.
8.Optional:Nurse call interface, Wireless Wifi monitoring system,Drop sensor.
Specifications:
Infusion rate | 0.1 - 2001 ml/h Increment: 0.01 ml/h |
Infusion accuracy | ±5% after correct calibration |
Applicable infusion set | Various brands of standard infusion sets |
Volume to be infused (VTBI) | 0-36000ml Increment: 0.01ml/h |
Volume infused | 0-36000 (ml) |
KVO rate | 0-10 ml/h |
Bolus rate | Manual Bolus/Automatic Bolus: 0.1~2001 ml/h |
Infusion mode | Rate mode, Drip mode, Time mode, Body Weight mode, Drug library mode, Micro mode Intermittent mode, Dose mode, Program mode, TPN mode, Shift mode
|
Purge rate | 0.1-2001 ml/h Purge VTBI: 0-36000 ml |
Air bubble detection | Ultrasound sensor detection with 6 levels of air in line |
Occlusion pressure | 13 adjustable occlusion levels |
Alarm | Use battery, Door open, Occlusion, Almost done, No operation, Infusion completion, Low Battery, Battery exhausted, malfunction
etc. |
Power supply | AC:100 ~ 240 V, 50 / 60 HZ |
Battery | Rechargeable Li_Polymer battery, 7.4 V 6800 mAh |
Battery charging time | 24 hours with power on, 7 hours with power off |
Battery operating time | 12 hours at 25 ml/h |
Power consumption | 35 VA |
Classification | Class I, type CF |
Waterproof | IP24 |
Dimension | 97*185*126 mm (L*W*H) |
Weight | 1.62Kg |
